DPIM-330F

UV inkjet digital printing machine

It can achieve 220mm~520mm wide format printing, and can choose flexo printing module, pre-flexographic cold foil stamping, printing customized spot color (purple, orange, green), digital cold stamping/digital varnish, post-flexo printing varnishing, forward and reverse offset printing, intermittent die-cutting, laminating module, defect quality management system, etc.

It can clearly print small characters and fine lines, and output beautiful color images with rich color gradations.

The UV inkjet principle directly uses the printing situation to reduce the amount of ink and save the cost of consumables to the greatest extent.

Applicable materials:

Films:PET/PVC/PP/PE/BOPP and other films

Paper:Synthetic paper, coated paper and aluminum foil and other special materials

Printing function

Maximun resolution:1200x600dpi (optional 1200x1200dpi)

Printing speed:30m~60m/min (depending on the material of the substrate)

Grayscale level:3

Digital printing accuracy:±0.06mm

Material width range:20mm~330mm (customized450mm and 520mm)

Maximum paper feed width:330mm (Standard model)

Maximum printing width:330mm (Standard model)

Material thickness dimension:0.02~0.5mm (depending on the material of the substrate)

Automatic overprinting system accuracy:±0.06mm

Ink

Ink Type:UV ink

Ink color configuration:Standard mode is CMYK, optional white + customized spot color (purple，orange，green)

Flexible printing function

Maximum flexographic printing speed:100m/min (depending on the material of the substrate)

Flexographic overprinting accuracy:±0.1mm

Offset printing accuracy:±0.15mm

Digital gold stamping/digital varnish

Maximum cold hot speed:30m/min

Glue thickness:Single row 0.1mm (optional double row 0.3mm)

Overprinting accuracy:±0.04mm

Intermittent die-cutting accuracy:±0.35mm

Media system

Maximum retraction/unrolling diameter:750mm

Maximum unwinding load bearing weight:150kg

Material Transfer:Retraction and unwinding servo control, constant tension retracting and retracting

Installation conditions:

Relative humidity:40%-60% (no condensation)

Ambient temperature:20°C-26°C

Power:45KW (Standard Version)

Power supply requirements:AC380V/50Hz/90A (Standard Version)

Air source:0.6-0.8Mpa

Equipment specifications

Equipment weight:7500KG (Standard Version)

Equipment size:7000mm (L) x 1600mm (W) x 1820mm (H) (Standard Edition)
