LPM-220

Lightweight digital printing machine

Entry-level inkjet printing machines ensure that customers reduce material production costs and improve efficiency while ensuring very low equipment investment costs.

It is suitable for industrial flexible production needs, expands customer label printing market capabilities, and increases competitive advantages.

The UV inkjet principle directly reduces the amount of ink in the form of printing, saving the cost of consumables to the greatest extent.

Applicable materials:

Films:PET/PVC/PP/PE/BOPP, shrink film and other films

Paper:Synthetic paper, wine label paper, coated paper, thermal paper, bright silver, aluminum foil and other special materials

Printing function

Maximun resolution:600x600dpi,1200-600dpi

Maximum printing Speed:30m-60m/min (depending on the properties of the material)

Grayscale level:3

Digital printing accuracy:±0.06mm

Material width range:20mm~330mm

Maximum paper feed width:330mm

Maximum printing width:220mm

Material thickness dimensions:0.04~0.5mm (depending on the properties of the material)

Ink

Ink Type:UV ink

Ink color configuration:The standard mode is CMYK

Media system

Maximum retraction/unwinding diameter:750mm

Maximum unwinding load:100kg

Material transfer:Retraction and unwinding servo control, constant tension retracting and retracting

Installation conditions:

Relative humidity:40%-60% (no condensation)

Ambient temperature:20°C-26°C

Power:30KW

Power supply requirements:AC380V/50Hz/60A

Air source:0.6-0.8Mpa

Equipment specifications

Equipment weight:3000KG

Equipment Dimensions:2900mm(L)x1700mm(W)x1900mm(H)
